Instructions:
The use of the rotor and the screen between the high-speed relative movement, the rapid mass of the massive particles in the rotor rolling, through the sieve into the grain, finished particles instantaneous discharge, less heat, high efficiency, good quality. Using frequency control, spindle speed adjustable, wide range; the use of lower drive, feed smoothly. The machine and the material contact parts and the appearance of part of the selection of high quality stainless steel, surface polishing treatment, respectively, and wet granulation and fluidized bed drying equipment supporting the use of easy disassembly, easy to clean, no cross infection, in line with GMP requirements.
Function:
Mainly for wet granulation and spray granulation and other bulk materials and undesirable tablets, according to the size of the size requirements of the whole grain; also on food, biscuits crushing recycling, and other coarse raw materials, crushed and granulated It is an ideal device for handling low-viscosity bulk and dendritic materials.
Technical Parameters:
Model | ZLJ250Y |
Production Capacity | 1500-2500 Kg/h |
Rotary Speed | 150-960 r/min |
Power | 380V,50Hz, 4Kw |
Dimension | 1600*700*1600 mm |
Machine Weight | 305 Kg |
Packing Weight | 420 Kg |
About equipment Other optional parts features:
1, with 50mm lifting function
2,50L silo + manual single leaf butterfly valve
3, the screen and the whole knife (square hole mesh with wet granule knife, round hole mesh with dry granule knife), the screen can be allocated according to their own needs.
